Rugged GNSS GPS Module with 2M Accuracy and 1.65~3.6V Voltage

Product Description:

Our product has a wide range of applications, from car navigation and traffic recording to drones and law enforcement cameras. It can also be used for high-definition cameras, surveying and mapping devices, handheld devices, smart wearables, and smart agriculture equipment.

• Concurrent reception of up to 3 GNSS (GPS, Galileo, GLONASS, BeiDou)
• Minimum current consumption
• Excellent positioning accuracy in urban canyons
• With security and integrity protection
• Supports all satellite augmentation systems
• Built-in low noise amplifier

Our product offers concurrent reception of up to 3 GNSS signals, namely GPS, Galileo, GLONASS, and BeiDou. This feature provides excellent positioning accuracy in challenging environments like urban canyons, where high-rise buildings interfere with signals.

In addition, our product has industry-leading low current consumption, making it ideal for handheld devices and battery-powered equipment. It comes with security and integrity protection, ensuring reliable and accurate positioning information.

Our product supports all satellite augmentation systems, including SBAS, QZSS, and DGPS. Its built-in low noise amplifier enhances the signal-to-noise ratio, improving accuracy and reliability.

Features:

• Product Name: GPS Module
• Model number: WT-62-UNL
• Agreement: NMEA-0183 Compliant Protocol Or Custom Protocol
• Power Consume: Operation Mode: 21 MA@3.0V, Power Saving Mode: 5.3 MA@3.0V (PSM, 1hz)
• Humidity range: 5% To 95% Non-condensing
• Accuracy: 2M

The GPS Module is a GPS Positioning Module that can be used as a Determining Module. It is NMEA-0183 Compliant Protocol Or Custom Protocol. It consumes 21 MA@3.0V in operation mode and 5.3 MA@3.0V in power saving mode (PSM, 1hz). The humidity range is 5% to 95% non-condensing and has an accuracy of 2M.

Technical Parameters:

Applications:

The OTW GPS Module has a maximum speed of 515 M/s and is available at several baud rates, ranging from 4800bps to 921600bps. The default baud rate is 9600bps. The module is highly sensitive, with tracking sensitivity of -167 DBM, capture sensitivity of -158 DBM, cold start sensitivity of -148dBm, and hot start sensitivity of -157dBm. This sensitivity ensures that the module can accurately track the location of any device it is attached to.

The OTW GPS Module, model number WT-62-UNL, is perfect for use in a variety of applications, including fleet management, vehicle tracking, personal tracking, marine navigation, and more. It can be used in cars, trucks, boats, and planes to provide real-time location tracking. It is also suitable for use in personal tracking devices, such as those used by hikers and outdoor enthusiasts.

The OTW GPS Module can be used in scenarios where location tracking is critical. For example, it can be used in emergency response vehicles, allowing dispatchers to track vehicles and ensure that first responders arrive at the scene of an emergency quickly. It can also be used in logistics and transportation, allowing businesses to track the location of their vehicles and goods in real-time.

The OTW GPS Module, model number WT-62-UNL, is a reliable and accurate locater module that is easy to install and use. It has a maximum acceleration of ≦ 4G, making it suitable for use in a variety of environments. Its compact size and affordable price make it an ideal choice for businesses and individuals looking for a cost-effective location tracking module.
