Product Details:
Place of Origin: China
Brand Name: OTW
Model Number: WT-11-UB
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: US $2.4 - 11.80/
Delivery Time: 7-10working days after receiving the payment
Payment Terms: T/T,Western Union
Supply Ability: Above US$100 Million
Contact Now

gnss module High Sensitivity GPS Module for Smart Agriculture and Wearables oem gps module

Description
Model Number: WT-11-UB Type: GNSS Module
Brand: OTW Operating Mode: GPS+GLONASS+ BDS
NMEA Messages: RMC,VTG,GGA,GSA,GSV,GLL Voltage: 1.65V To 3.6V
Power Consumption: Running Mode 16.5mA @3.0V Size: 9.7mm*10.1mm*2.4mm
Highlight:

high sensitivity GPS module

,

GNSS module for smart agriculture

,

OEM GPS module for wearables

GNSS Module High Sensitivity GPS Module for Smart Agriculture and Wearables OEM GPS Module
Product Attributes
Attribute Value
Model Number WT-11-UB
Type GNSS Module
Brand OTW
Operating mode GPS+GLONASS+BDS
NMEA messages RMC,VTG,GGA,GSA,GSV,GLL
Voltage 1.65V to 3.6V
Power consumption Running Mode 16.5mA @3.0V
Size 9.7mm*10.1mm*2.4mm
Overview
gnss module High Sensitivity GPS Module for Smart Agriculture and Wearables oem gps module 0
Applications
  • Car navigation, traffic recorder
  • Drones, law enforcement cameras
  • HD camera, surveying and mapping
  • Handheld device
  • Smart wear
  • Smart agriculture
gnss module High Sensitivity GPS Module for Smart Agriculture and Wearables oem gps module 1
Key Features
  • Supports GPS/QZSS, GLONASS
  • Combines low power consumption and high sensitivity
  • Strong anti-interference ability
  • Low cost, ultra-small size
gnss module High Sensitivity GPS Module for Smart Agriculture and Wearables oem gps module 2 gnss module High Sensitivity GPS Module for Smart Agriculture and Wearables oem gps module 3
Technical Specifications
Model WT-11-UB
Receiver type GPS/QZSS L1 C/A GLONASS L1
Agreement NMEA-0183 compliant protocol or custom protocol
Available baud rate 4800bps~921600bps (default 9600bps)
Channel 56
Sensitivity Tracking: -161dBm
Hot start: -148dBm
Cold start: -148dBm
Cold start Average 29 seconds
Hot start Average 1 second
Accuracy Horizontal Position: average, SBAS < 2.5m
Max Height 18000 M
Max Speed 515 m/s
Max Acceleration ≤ 4G
Regeneration frequency 0.25Hz-10 Hz
Positioning mode A-GNSS
Port 2 UART, 2 SPI, 1 I2C
Type 18PIN LCC package
Size 10.1mm * 9.7mm * 2.4mm (+/- 0.5mm)
Voltage 1.8V~3.6V
Power Consume Operation mode: 16.5mA@3V
Power saving mode: 4.5mA@3V
Humidity range 5% to 95% non-condensing
Working Temperature -40℃ to 85℃
Storage Temperature -40℃ to 125℃
