RTK Development Board with Centimeter-Level Positioning, Integrated 4G Module, and Dual-Frequency RTK Algorithm for High-Precision GNSS Applications

RTK Development Board with Centimeter-Level Positioning, Integrated 4G Module, and Dual-Frequency RTK Algorithm for High-Precision GNSS Applications
RTK Development Board with Centimeter-Level Positioning, Integrated 4G Module, and Dual-Frequency RTK Algorithm for High-Precision GNSS Applications RTK Development Board with Centimeter-Level Positioning, Integrated 4G Module, and Dual-Frequency RTK Algorithm for High-Precision GNSS Applications RTK Development Board with Centimeter-Level Positioning, Integrated 4G Module, and Dual-Frequency RTK Algorithm for High-Precision GNSS Applications

Large Image :  RTK Development Board with Centimeter-Level Positioning, Integrated 4G Module, and Dual-Frequency RTK Algorithm for High-Precision GNSS Applications

Product Details:
Place of Origin: CHINA
Brand Name: OTW
Model Number: WT-43-RD-4G
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 45.88-49.88usd per piece
Packaging Details: Paper box
Delivery Time: 5-8 working days
Payment Terms: T/T,AliPay,PayPal
Supply Ability: 10000 pcs/day
Contact Now

RTK Development Board with Centimeter-Level Positioning, Integrated 4G Module, and Dual-Frequency RTK Algorithm for High-Precision GNSS Applications

Description
Maximum Speed: 515 M/s Channel: 128
Available Baud Rate: 4800bps~921600bps(default 115200bps) Regeneration: 1Hz -20 Hz(default 1Hz）
Maximum Height: 18000 M Power Consume: 80 MA @5V
Receiver Type: BDS:B1I/B1C & B2a GPS/QZSS:L1C/A & L5 GLONASS:L1 Galileo:E1 & E5a
Highlight:

Centimeter-Level Positioning RTK Development Board

,

Integrated 4G Module GNSS Receiver Evaluation Board

,

Dual-Frequency RTK Algorithm GPS Module Development Board

WT-43-RK-4G RTK Board Card
Integrated high-precision positioning board card enabling centimeter-level accuracy in various environments.
Applications
  • GIS collection and handheld terminals
  • Displacement monitoring and base stations
  • Urban tunnels and canyon positioning
  • Communication positioning systems
  • Complex environments and high-speed motion scenarios
  • UAV and drone applications
  • Intelligent Internet of Things
  • Intelligent driving and automotive systems
Product Features
  • Multi-system support: BDS B1I/B2a/B1C, GPS L1C/A/L5, GAL E1/E5a, GLONASS L1 four-system dual frequency
  • Integrated 4G module with inertial navigation for urban tunnel and canyon positioning
  • Built-in dual-frequency RTK algorithm
  • Ultra-high precision with centimeter-level positioning accuracy
  • Low power consumption with fast positioning capabilities
  • Integrated LORA data transmission for direct base station communication
Technical Specifications
Parameter Specification
Maximum Altitude 18,000 M
RAWX Support Multi-GNSS Raw Measurement Data Output
Cold Start Time Average 24 Seconds
Hot Start Time Average 2 Seconds
Algorithm Integrated Dual Frequency RTK Algorithm
Working Temperature -40℃ to 85℃
Storage Temperature -40℃ to 105℃
Sensitivity Tracking: -167dBm, Capture: -158dBm, Cold Start: -148dBm
Power Consumption 80 mA @ 5V
Baud Rate 4800bps to 921600bps (default: 115200bps)
Positioning Accuracy Horizontal: 1cm+1ppm CEP50; Elevation: 2cm+1ppm CEP50
Dimensions 43.11mm × 43.1mm × 8.2mm
Product Details

Product Name: Development Board

Model Number: WT-43-RD-4G

Description: GNSS/GPS Receiver Evaluation Board with SMA USB, GPS Module Development Board

Minimum Order Quantity: 1 piece

Packaging: Paper box

Delivery Time: 5-8 working days

Payment Terms: T/T, AliPay, PayPal

Supply Ability: 10,000 pieces per day

Origin: China
